Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-40S
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X125-40S Technical Details
- Model Code: MBLCJ20X125-40S
- Bore Size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Adjustable Cushioning: Dual-sided air cushion with 3-stage adjustment
- Operating Pressure: 0.05-1.0 MPa (7-145 psi)
- Port Size: Rc1/8 (NPT1/8 optional)
- Piston Speed: 50-800 mm/s (lubricated)
- Ambient Temperature: -20℃ to 80℃ (non-freezing)
- Mounting Type: Double pivot bracket (40S code)
- Body Material: Hard-anodized aluminum alloy
- Seal Material: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 0.68 kg (with bracket and accessories)
- Dimensions:
- Extended Length: 250mm (stroke + body)
- Retracted Length: 125mm
- Body Diameter: 34mm
- Bracket Width: 52mm
Ultra-compact cylinder featuring precision-machined guide rods and integrated shock absorption. The MBLCJ series incorporates a unique anti-rotation mechanism and T-slot mounting compatibility. Optimized for high-frequency operations (up to 5 cycles/sec) with wear-compensation design for extended service life. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC fixture systems
- Label application mechanisms in packaging lines
- Medical device assembly automation
- 3D printer component actuation
Installation protocol:
Maintain 0.5-1mm clearance between cushion screws and end caps during adjustment.
Use M4x0.7 mounting screws with 6.8 grade or higher. Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
