Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-50
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X125-50 Technical Details
- Model: MBLCJ20X125-50
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Front adjustable rubber + rear fixed cushion
- Mounting style: Basic type (no built-in mounting)
- Port size: M5 (Rc1/8/NPT1/8 optional)
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (Nitrile rubber)
- Rod material: Stainless steel (SUS304)
- Weight: 0.68 kg (excluding accessories)
- Dimensions (L×W×H):
- Extended length: 229mm
- Retracted length: 104mm
- Body width: 32mm
- Mounting height: 50mm
- Protection rating: IP40 (dust protected)
- Lubrication: Pre-lubricated (DOP-free grease)
Ultra-compact cylinder with precision stroke control, featuring a unique dual-cushion system that reduces impact noise by 30% compared to standard models. The front adjustable cushion allows fine-tuning of end-position deceleration (adjustment range: 0-5mm), while the fixed rear cushion ensures consistent performance. Anodized surface treatment provides enhanced corrosion resistance for humid environments.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical packaging
- Precision alignment mechanisms for optical equipment
- Compact sorting gates in logistics automation
- Dental chair positioning systems
Installation note:
Maximum side load capacity 15N. For vertical installations exceeding 45° tilt,
use guided mounting brackets (AMCJ series recommended). Lubricate every 500,000 cycles
with ISO VG32 turbine oil. Avoid using in environments with phosphate ester hydraulic fluids.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
