Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-50S
$44.16
Regular price
$51.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLCJ20X125-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with AIRTAC enterprise standards, featuring an aluminum round tube barrel construction;
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
Installation guidance:
Apply silicone-based lubricant (ISO VG32) to rod before initial use.
For vertical mounting, reduce operating pressure by 20% to compensate
for gravitational load. Cushion adjustment requires 2mm hex key (included).
Critical note:
Do not exceed 80% of maximum pressure when using magnetic sensors.
Maintain 0.5mm minimum clearance between cylinder body and mounting surface
for thermal expansion.
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ20X125-50S Adjustable Mini Cylinder Specifications
- Model: MBLCJ20X125-50S
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Mounting style: Front flange (NF) with rear pivot base (MB)
- Port size: 1/8" NPT (M5 optional via adapter)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Cushioning: Adjustable needle valve (both ends)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Piston material: Hard anodized aluminum alloy
- Seal type: NBR rubber (FDA compliant options available)
- Built-in sensors: 2x magnetic reed switches (DC3-24V 30mA max)
- Weight: 680g ±5% (excluding accessories)
- Dimensions: 196mm(L) × 40mm(W) × 40mm(H) (full extension)
- Rod thread: M6×1.0 external thread (stainless steel)
- Repetition accuracy: ±0.2mm
- Max speed: 500mm/s (with cushion adjustment)
Ultra-compact linear actuator featuring dual adjustable pneumatic cushions for precise end-position deceleration. The nickel-plated piston rod and corrosion-resistant construction enable reliable operation in humid environments. Integrated mounting slots allow 180° sensor positioning flexibility.
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms for CNC tooling
- Pharmaceutical blister packaging machines
- Micro-positioning stages in optical alignment systems
- Cleanroom-compatible automation equipment
Installation guidance:
Apply silicone-based lubricant (ISO VG32) to rod before initial use.
For vertical mounting, reduce operating pressure by 20% to compensate
for gravitational load. Cushion adjustment requires 2mm hex key (included).
Critical note:
Do not exceed 80% of maximum pressure when using magnetic sensors.
Maintain 0.5mm minimum clearance between cylinder body and mounting surface
for thermal expansion.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
