Airtac MDJ Adjustable Cylinder MDJ10X10-10S
AirTAC MDJ Adjustable Cylinder MDJ10X10-10S Specifications
- Model: MDJ10X10-10S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 10mm
- Stroke: 10mm (adjustable)
- Adjustment range: 0-10mm (continuous)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Rubber buffer + adjustable stopper
- Mounting style: Basic type (no fixed mount)
- Port size: M5x0.8
- Material: Aluminum alloy cylinder tube, stainless steel piston rod
- Seal material: NBR
- Weight: 0.45kg ±5%
- Dimensions (L×W×H): 72mm × 25mm × 25mm (full retraction)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (maintenance-free)
Compact stroke-adjustable pneumatic cylinder with integrated mechanical stopper for precise end-position control. Features dual chrome-plated piston rods for enhanced wear resistance and anti-corrosion properties. The micrometer-style adjustment mechanism allows ±0.2mm repeat positioning accuracy. Optional magnetic version available for position sensing.
- Precision jig positioning in CNC machining
- Component pressing with force control
- Micro-adjustment in semiconductor handling systems
- Packaging machine stopper mechanisms
- Automated test equipment limit stops
- Textile machinery tension control
Installation tip:
Use locking nuts (not included) on both ends of adjustment screws after calibration.
For optimal performance, maintain air supply dew point below 3℃ and install
downstream speed controllers. Lubricate guide shafts monthly in high-cycle applications (>500k cycles/yr).
| Property | Property Value |
|---|---|
| sku | MDJ10X10-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
