Airtac MDJ Adjustable Cylinder MDJ10X15-10
$30.00
Regular price
$37.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MDJ10X15-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with enterprise standards;
2. Features multiple mounting configurations for simplified installation and operation;
3. Stackable design allows multi-cylinder alignment, optimizing spatial efficiency;
4. High-precision piston rod guidance system operates lubrication-free;
5. Extensive range of models/specifications available for diverse application requirements;
6. Optional high-temperature seals ensure reliable performance at 150°C (optional feature).
Category: Adjustable Cylinders | Brand: Airtac | Series: MDJ
Installation tip:
Use thread locker on adjustment screws after calibration.
Maximum permissible lateral load: 2.5N at full extension.
Lubricate with ISO VG32 hydraulic oil if used without air lubricator.
AirTAC MDJ Adjustable Cylinder MDJ10X15-10 Technical Details
- Model: MDJ10X15-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø10mm
- Stroke: 15mm (mechanically adjustable)
- Operating pressure: 0.05–0.9 MPa
- Piston speed: 50–700 mm/s
- Cushioning: Rubber buffer + adjustable stroke screw
- Port size: M5×0.8 (Rc1/8 optional)
- Ambient temperature: -10℃ to 80℃
- Mounting type: Front flange (standard), optional side mount
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR (nitrile) seals
- Weight: 0.23 kg (excluding accessories)
- Dimensions: 75mm(L) × 32mm(W) × 32mm(H) (retracted position)
Precision mini cylinder with stroke adjustment mechanism, featuring dual locking nuts for position fixation. The hex-shaped body prevents rotation during adjustment. Integrated air ports allow 360° orientation flexibility. Compatible with ISO 6432 mounting accessories.
Common Applications:
- Precision positioning in SMT component placement
- Clamping force adjustment in micro-assembly jigs
- Paper feed control in compact printers
- Valve actuation in analytical instruments
- Robotic end-effector position fine-tuning
Installation tip:
Use thread locker on adjustment screws after calibration.
Maximum permissible lateral load: 2.5N at full extension.
Lubricate with ISO VG32 hydraulic oil if used without air lubricator.
| Property | Property Value |
|---|---|
| sku | MDJ10X15-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
