Airtac MDJ Adjustable Cylinder MDJ10X25-20S
AirTAC MDJ Adjustable Cylinder MDJ10X25-20S Technical Details
- Model: MDJ10X25-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 10mm
- Stroke: 25mm (adjustable range: 0-20mm)
- Operating pressure: 0.05-0.9 MPa
- Cushioning type: Adjustable elastic buffer
- Mounting style: Foot-mounted (MF1)
- Port size: M5x0.8 (standard)
- Temperature range: -10℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber seals
- Weight: 0.45kg ±3%
- Dimensions:
- Total length (extended): 87mm
- Body diameter: Φ20mm
- Mounting hole spacing: 25mm (center-to-center)
- Rod thread: M5x0.8 (external)
Precision mini cylinder featuring patented adjustable stroke mechanism with 0.5mm graduation marks. The dual-channel design allows dynamic stroke modification without disassembly. Chrome-plated rod resists side loads up to 2N·m. Integrated wear-resistant bushings ensure 2,000km+ service life under continuous operation.
- PCB component insertion machines
- Pharmaceutical capsule filling systems
- Textile machinery thread tension control
- Automotive window regulator testing jigs
- 3D printer filament feed mechanisms
Installation protocol:
Use locknuts (included) for stroke limiter fixation. Lubricate with ISO VG32 turbine oil
before initial operation. Avoid angular misalignment exceeding ±2° during mounting.
| Property | Property Value |
|---|---|
| sku | MDJ10X25-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
