Airtac MDJ Adjustable Cylinder MDJ10X35-30S
$42.77
Regular price
$50.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MDJ10X35-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with enterprise standards;
2. Features multiple mounting configurations for simplified installation and operation;
3. Stackable design allows multi-cylinder alignment, optimizing spatial efficiency;
4. High-precision piston rod guidance system operates lubrication-free;
5. Extensive range of models/specifications available for diverse application requirements;
6. Optional high-temperature seals ensure reliable performance at 150°C (optional feature).
Category: Adjustable Cylinders | Brand: Airtac | Series: MDJ
Operation Tip:
For optimal cushioning performance, adjust buffer screws while observing motion - start with 1/4 turn increments. Always lubricate with ISO VG32 turbine oil (N2 grade) when using non-lubricated air.
AirTAC MDJ Adjustable Cylinder MDJ10X35-30S Technical Specifications
- Model Code Breakdown: MDJ10X35-30S = MDJ series, 10mm bore, 35mm stroke, 30mm adjustable buffer
- Bore Size: Ø10 mm (precision honed cylinder tube)
- Stroke: 35 mm (±1mm tolerance)
- Adjustment Type: External screw-type stroke adjustment with locknut
- Buffer Mechanism: Progressive rubber cushioning (front/rear adjustable)
- Operating Pressure: 0.15-0.8 MPa (1.5-8 bar)
- Temperature Range: -20℃ to +80℃ (dry air required below 0℃)
- Port Size: M5x0.8 (standard) or G1/8 optional
- Buffer Stroke: 3-5 mm adjustable range
- Mounting Style: Basic type (MF1) with axial mounting holes
- Rod Thread: M5x0.8 external thread (stainless steel)
- Cushion Material: NBR rubber with wear-resistant additive
- Tube Material: Anodized aluminum alloy
- Piston Material: Die-cast aluminum with magnetic ring option
- Seals: NBR standard (FKM available for high temp)
- Protection Class: IP40 (dust protected)
- Weight: 0.25 kg (without accessories)
- Dimensions: 100mm(L) × 40mm(W) × 40mm(H) (extended length: 135mm)
Precision mini cylinder featuring dual-direction adjustable pneumatic cushioning for controlled deceleration. The through-rod design allows external stroke adjustment via hexagonal wrench (included). Anti-rotation mechanism ensures stable linear motion. Compatible with magnetic sensors for position feedback (sensor groove pre-machined).
Ideal for:
- Precision alignment mechanisms in semiconductor handlers
- Clamping force adjustment in micro-injection molding
- Variable stroke applications in pharmaceutical blister packaging
- Optics positioning stages requiring vibration-free stops
- Laboratory automation with space constraints
Operation Tip:
For optimal cushioning performance, adjust buffer screws while observing motion - start with 1/4 turn increments. Always lubricate with ISO VG32 turbine oil (N2 grade) when using non-lubricated air.
Configuration Options:
- Rod end types: Female thread (standard), clevis, or flange
- Sensor compatibility: M9/M12 proximity switches
- Custom stroke lengths available (15-100mm)
- High-temp version withstands 120℃ (FKM seals)
| Property | Property Value |
|---|---|
| sku | MDJ10X35-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | 35mm |
