Airtac MDJ Adjustable Cylinder MDJ10X40-10S
AirTAC MDJ Adjustable Cylinder MDJ10X40-10S Technical Specifications
- Model Code: MDJ10X40-10S
- Type: Compact double-rod adjustable cylinder
- Bore size: 10mm (0.39")
- Stroke: 40mm (1.57")
- Operation: Double-acting
- Working pressure: 0.15-0.8 MPa (21.7-116 PSI)
- Piston rod diameter: 4mm (0.16")
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seals: NBR (Nitrile rubber)
- Cushioning: Adjustable buffers at both ends
- Port size: M5x0.8 (Two ports)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 0.28kg (0.62 lbs)
- Dimensions (L×W×H):
- Extended length: 80mm (3.15")
- Retracted length: 40mm (1.57")
- Body width: 20mm (0.79")
- Mounting height: 10mm (0.39")
- Optional features: Built-in magnetic sensor slot (non-contact type)
Precision mini cylinder with dual-rod stabilization and micrometer-grade positioning accuracy (±0.1mm repeatability). Features an integrated shock absorption system with 270° rotary adjustment knobs for smooth end-of-stroke deceleration. The hardened chromium piston rod resists side loads up to 1.5N·m. Compatible with ISO 6432 mounting accessories.
- PCB board handling robots
- Semiconductor wafer alignment stages
- Pharmaceutical blister packaging machines
- Micro-precision clamping fixtures
- Optical lens positioning systems
Installation protocol:
Use alignment jigs during mounting to ensure parallel rod movement.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maximum side load tolerance requires guide rail support in horizontal applications.
| Property | Property Value |
|---|---|
| sku | MDJ10X40-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
