Airtac MDJ Adjustable Cylinder MDJ10X5-10
AirTAC MDJ Adjustable Stroke Cylinder MDJ10X5-10 Technical Specifications
- Model: MDJ10X5-10
- Type: Compact adjustable stroke cylinder (double acting)
- Bore size: Ø10mm
- Stroke range: 5-50mm (adjustable via built-in stopper)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (Rc1/8 adaptor included)
- Cushioning: Rubber buffer + adjustable dampers
- Material: Aluminum alloy body, CRCA mounting brackets
- Mounting: Standard ISO 6432 (optional side/face mounts)
- Weight: 220g ±5% (without accessories)
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H) (retracted position)
- Rod thread: M5×0.8 external thread (front end)
- Protection rating: IP54 (standard seals)
Precision micro cylinder featuring stepless stroke adjustment through its unique rotating stopper mechanism. The integrated locknut maintains position stability during repetitive operations. Dual anti-rotation guides ensure straight-line movement accuracy (±0.2mm repeatability). Compatible with auto switches (M9/M5) via T-slot mounting.
- Precision part positioning in SMT equipment
- Clamping force adjustment in PCB drilling machines
- Label applicator pressure control systems
- Medical device component assembly
- Photovoltaic panel alignment mechanisms
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maximum side load: 2.5N. For vertical mounting,
use anti-drop retention clips (sold separately).
| Property | Property Value |
|---|---|
| sku | MDJ10X5-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
