Airtac MFD Double Rod Miniature Cylinder MFD20X160
1. Compliance with JS Standard specifications;
2. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed shock-absorbing pads on both end covers to mitigate directional change impacts;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Riveted enclosure design combining end covers with precision stainless steel barrel ensuring secure connection;
6. High-strength stainless steel tube construction offering superior corrosion resistance;
7. Compact footprint - shorter overall length compared to ISO6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with multiple accessories for customized solutions.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: MFD
AirTAC MFD Double-Rod Miniature Cylinder MFD20X160 Specifications
- Model: MFD20X160
- Type: Double-acting, dual-rod compact cylinder
- Bore size: 20mm
- Stroke: 160mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Port thread: M5×0.8 or PT1/8 (user selectable)
- Cushioning: Adjustable rubber buffers at both ends
- Piston speed: 50–700 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 1.2 kg (excluding accessories)
- Dimensions (L×W×H): 220mm × 30mm × 30mm (full extension length may vary by ±2mm)
- Mounting options: Foot-mounted (standard), front flange (optional)
- ISO standard: 6432 compliant
Ultra-slim dual-rod pneumatic cylinder engineered for precision linear motion in confined spaces. Features synchronized output force from both ends (max 125N at 0.6MPa) and anti-rotation design for stable load guidance. The hardened piston rods and triple-lip seals ensure over 3,000km service life under regular maintenance.
- Semiconductor wafer handling robots
- Precision clamping in PCB assembly lines
- Medical device positioning systems
- Packaging machine ejector mechanisms
- Automated optical inspection (AOI) equipment
Installation note:
Align within 0.2mm perpendicularity tolerance during mounting. Lubricate with ISO VG32 hydraulic oil monthly.
Avoid side load exceeding 15N. Use clean dry air (40μm filtration, dew point -20℃ below ambient).
| Property | Property Value |
|---|---|
| sku | MFD20X160 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | 160mm |
