Airtac MFD Double Rod Miniature Cylinder MFD20X200S
1. Compliance with JS Standard specifications;
2. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed shock-absorbing pads on both end covers to mitigate directional change impacts;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Riveted enclosure design combining end covers with precision stainless steel barrel ensuring secure connection;
6. High-strength stainless steel tube construction offering superior corrosion resistance;
7. Compact footprint - shorter overall length compared to ISO6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with multiple accessories for customized solutions.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: MFD
AirTAC MFD20X200S Double Rod Miniature Cylinder Specifications
- Model: MFD20X200S
- Type: Double-acting twin rod cylinder
- Bore size: Ø20mm
- Stroke: 200mm (standard) ±0.8mm tolerance
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Port thread: M5×0.8 (standard) / NPT1/8 optional
- Piston speed: 50–700 mm/s
- Ambient temperature: -10℃ to 80℃
- Seal material: Polyurethane (PU) / NBR optional
- Rod material: Chrome-plated carbon steel
- Body material: Anodized aluminum alloy
- Protection rating: IP54 (standard) / IP67 optional
- Weight: 580g ±2% (excluding accessories)
- Dimensions:
- Extended length: 332mm
- Retracted length: 132mm
- Body width: 40mm
- Mounting height: 20mm
Ultra-compact twin rod actuator with symmetrical force output, featuring precision ground rods and wear-resistant guides. The dual-rod design eliminates rotational torque during operation, making it ideal for precision alignment applications. Compatible with magnetic sensors (sensor slot pre-machined). Requires 5μm filtered air with 1-2 drops of ISO VG32 oil per m³.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Pharmaceutical blister packaging machines
- Optical lens positioning systems
- Laboratory automation sample handlers
Installation recommendation:
For vertical mounting applications exceeding 45° inclination,
use external rod locks or braking units to prevent unintended
movement during power loss. Maintain 0.5mm minimum clearance
between rods and adjacent components.
| Property | Property Value |
|---|---|
| sku | MFD20X200S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <200mm> |
