Airtac MFD Double Rod Miniature Cylinder MFD20X25
1. Compliance with JS Standard specifications;
2. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed shock-absorbing pads on both end covers to mitigate directional change impacts;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Riveted enclosure design combining end covers with precision stainless steel barrel ensuring secure connection;
6. High-strength stainless steel tube construction offering superior corrosion resistance;
7. Compact footprint - shorter overall length compared to ISO6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with multiple accessories for customized solutions.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: MFD
AirTAC MFD20X25 Double-Rod Miniature Cylinder Specifications
- Model: MFD20X25
- Type: Compact double-rod cylinder (non-rotating)
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 25mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Port size: M5×0.8 (dual ports both ends)
- Cushion type: Rubber buffer + adjustable
- Mounting style: Basic (optional foot/block mounts)
- Rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 280g ±5%
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H)
- Protection rating: IP40 (dust resistant)
- Max speed: 500mm/s (with cushioning)
Ultra-compact dual-action cylinder designed for precision linear motion in confined spaces. Features symmetrical double-rod configuration for balanced force distribution and optional magnetic piston for position sensing. The anti-rotation design maintains orientation stability during operation.
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical equipment
- Lens positioning systems in optical instruments
- Precision clamping in watchmaking machinery
- Automated pipette control in lab automation
Installation tip:
Maintain 0.5-1mm clearance between rods and load during alignment.
Use speed controllers (ASC-06) for optimal cushioning adjustment.
Lubricate with ISO VG32 hydraulic oil if operated below -5℃.
| Property | Property Value |
|---|---|
| sku | MFD20X25 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
