Airtac MFD Double Rod Miniature Cylinder MFD20X300S
1. Compliance with JS Standard specifications;
2. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed shock-absorbing pads on both end covers to mitigate directional change impacts;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Riveted enclosure design combining end covers with precision stainless steel barrel ensuring secure connection;
6. High-strength stainless steel tube construction offering superior corrosion resistance;
7. Compact footprint - shorter overall length compared to ISO6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with multiple accessories for customized solutions.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: MFD
AirTAC MFD20X300S Double Rod Miniature Cylinder Specifications
- Model: MFD20X300S
- Bore size: 20mm
- Stroke: 300mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (standard), G1/8 optional
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: Basic (no pre-mount accessories)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR wear-resistant seals
- Weight: 1.28kg (with rods)
- Dimensions: 360mm(L) × 34mm(W) × 34mm(H)
Ultra-compact dual-rod cylinder designed for symmetrical force applications requiring precise linear motion. Features twin piston rods for enhanced stability and reduced rotation during operation. Corrosion-resistant construction with integrated mounting slots for flexible installation. Requires ISO 8573-1 class 3 or cleaner compressed air.
- Precision alignment in semiconductor wafer handling
- Dual-gripper mechanisms in pick-and-place robots
- Simultaneous clamping in CNC fixture systems
- Mirror movement in optical testing equipment
- Bi-directional actuation in medical analyzers
Installation guidelines:
Maintain parallel alignment of both rods during mounting.
Lubricate with ISO VG32 hydraulic oil before initial use.
Avoid side loads exceeding 15N. For vertical installations,
use rod-end support brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | MFD20X300S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | 300mm |
