Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X10
$38.37
Regular price
$45.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MICD16X10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standard (for sizes 8-25);
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
Installation tips:
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Cylinder MICD16X10 Specifications
- Model: MICD16X10
- Type: Double-acting with air cushioning (twin rod)
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Adjustable pneumatic cushion at both ends
- Port size: M5x0.8 (standard) / Optional NPT1/8
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s (optimal range 100–500 mm/s)
- Rod material: Stainless steel SUS304 (chrome-plated optional)
- Tube material: Aluminum alloy with hard anodized surface
- Seal type: NBR rubber (FDA compliant options available)
- Mounting style: Dual front/rear threaded holes (M5x0.8) + side mounting slots
- Weight: 78g ±2g (excluding accessories)
- Dimensions:
- Length: 64mm (basic length) + stroke
- Width: 32mm (max body width)
- Height: 22mm (body height from mounting surface)
- Rod diameter: 4mm (double rods)
- Rod thread: M4x0.7 at both ends
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if maintenance required)
- Protection rating: IP67 (standard wipers)
Ultra-compact twin-rod cylinder featuring symmetrical force output and space-saving design. The integrated air cushion mechanism minimizes end-impact vibration (≤0.5m/s² at 0.5MPa), making it ideal for precision positioning in confined spaces. Special anti-rotation design maintains parallel rod alignment even under side loads.
Recommended Applications:
- PCB handling robots in electronics manufacturing
- Micro-dispensing systems for adhesives/lubricants
- Optical lens positioning stages
- Laboratory automation sample handlers
- Medical device actuation mechanisms
- 3D printer auxiliary mechanisms
Installation tips:
- Maintain 0.5mm minimum clearance between rods during parallel installation
- Use flexible couplings to compensate for ±0.2mm alignment tolerance
- For vertical mounting, add 10-15% extra thrust capacity margin
- Cycle rate: Max 80% duty cycle at 3Hz operation
| Property | Property Value |
|---|---|
| sku | MICD16X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
