Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X100
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Air Cushion Double Rod Mini Cylinder MICD16X100 Specifications
- Model: MICD16X100
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.7 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: M5x0.8 (dual ports at both ends)
- Piston speed: 50-750 mm/s (lubricated condition)
- Ambient temperature: -10℃ to 70℃
- Mounting type: Basic front flange (NF series compatible)
- Rod thread: M6x1 (external thread both ends)
- Material:
- Tube: Aluminum alloy, hard anodized
- Piston rod: SUS304 stainless steel
- Seals: NBR (standard), optional FKM
- Weight: 0.52 kg (with standard accessories)
- Dimensions:
- Total length: 162mm (at mid-position)
- Width: 32mm (flange mounting surface)
- Height: 42mm (including rod ends)
- Mounting hole spacing: 25mm (vertical) × 18mm (horizontal)
Ultra-compact double-rod cylinder featuring dual adjustable pneumatic cushions for precise end-position damping. The symmetrical design minimizes lateral load during operation, with corrosion-resistant construction suitable for cleanroom environments. Integrated mounting grooves allow direct sensor installation without brackets.
- PCB board clamping/positioning in SMT machines
- Precision glass panel handling robots
- Pharmaceutical blister packaging mechanisms
- Semiconductor wafer transfer systems
- High-speed sorting gates in food processing
Installation tip:
Maintain strict alignment between cylinder axis and load movement direction.
For full-stroke applications, reduce operating pressure to 0.3MPa during initial
commissioning to verify cushion adjustment. Use only ISO VG32 hydraulic oil
for lubrication if required.
| Property | Property Value |
|---|---|
| sku | MICD16X100 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 100mm |
