Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X10S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Mini Cylinder with Air Cushion - MICD16X10S
- Model: MICD16X10S
- Bore size: 16mm
- Stroke: 10mm
- Cushion type: Adjustable air cushion (dual-action)
- Operation: Double-acting
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Mounting type: Standard foot mounting (NF1)
- Piston material: Aluminum alloy with hard anodization
- Rod material: SUS304 stainless steel
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65
- Weight: 0.22kg ±2%
- Dimensions (L×W×H): 50mm × 16mm × 16mm (excluding rod extension)
- Max theoretical thrust: 13.3N @0.5MPa
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact dual-rod cylinder featuring integrated air cushioning for smooth end-of-stroke deceleration. The twin-rod design provides balanced force distribution and enhanced lateral load capacity. Precision honed tube ensures ≤0.2mm positioning repeatability. Optional magnetic version available for position sensing (add "-M" suffix).
- PCB handling in SMT equipment
- Precision alignment mechanisms in optical instruments
- Component ejection systems in micro-molding machines
- Clamping fixtures for medical device assembly
- Actuation in semiconductor wafer processing
Installation guidance:
For optimal performance, maintain ≤0.05mm perpendicularity between rod axis and load direction.
Use Cushion Locknut (ASD6) to secure cushion adjustment. Lubricate through port using ISO VG32
turbine oil if operated beyond 6 months without maintenance.
| Property | Property Value |
|---|---|
| sku | MICD16X10S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
