Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X125
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Cylinder MICD16X125 Specifications
- Model: MICD16X125
- Type: Double-acting cylinder with air cushion (adjustable buffer)
- Bore size: Ø16mm
- Stroke: 125mm (±1.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushion stroke: 8mm (front) / 8mm (rear)
- Port thread: M5×0.8 (standard) or NPT1/8 (optional)
- Piston speed: 50–800 mm/s
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile) with wear-resistant ring
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Weight: 0.45kg (without accessories)
- Dimensions: 180mm(L) × 40mm(W) × 40mm(H) (at mid-stroke position)
- Mounting options: Front flange (MF1), rear pivot (MP4), or side lug (MA3)
- Protection rating: IP54 (standard wiper seal)
Ultra-compact dual-rod cylinder featuring precision air cushioning for shock absorption at both stroke ends. The MICD series combines high rigidity (20% stronger than standard mini cylinders) with a 22% weight reduction through optimized aluminum alloy construction. Dual rod design prevents rotation during operation, ideal for precise positioning tasks. Requires 5μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC machining centers
- Label application mechanisms in packaging lines
- Optical lens positioning systems
- Pharmaceutical blister packing machines
Installation notes:1. Maintain ≤0.1mm alignment tolerance during mounting
2. Adjust cushion needles gradually (1/4 turns) for optimal damping
3. Lubricate through air supply (ISO VG32 turbine oil recommended)
4. Allow 15mm clearance for rod extension at both ends
| Property | Property Value |
|---|---|
| sku | MICD16X125 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 125mm |
