Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X125S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Dual Rod Mini Cylinder with Air Cushion MICD16X125S
- Model: MICD16X125S
- Type: Double-acting dual rod cylinder with adjustable air cushion
- Bore size: 16 mm
- Stroke: 125 mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Foot mounting (Standard), optional flange/bracket types available
- Port size: M5x0.8 (1/8" NPT adapters optional)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.54 kg (1.19 lbs)
- Dimensions:
- Total length (L): 203 mm (stroke + 39mm base length)
- Body width (W): 45 mm
- Height with rods (H): 32 mm (body) / 64 mm (including extended rods)
- Rod diameter: 6 mm
- Max theoretical thrust: 126N@0.6MPa
- Lubrication: Pre-lubricated (Oil-free operation possible with special seals)
Ultra-compact dual-rod cylinder featuring precision air cushioning for smooth end-stroke deceleration. The symmetrical dual-rod design ensures balanced force distribution and improved stability during bi-directional movements. Built with corrosion-resistant materials and IP54-rated protection against particulate contamination. Requires 5-40μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality standards.
- Precision alignment mechanisms in semiconductor handling equipment
- Clamping fixtures for CNC machining centers
- Vertical Z-axis positioning in 3D printing/pick-and-place systems
- Dual-sided actuation in packaging machine sealing heads
- Medical device assembly requiring symmetrical force application
Installation note:
Maintain 0.05mm/m alignment tolerance during mounting. For vertical installations,
use rod-end supports to prevent side load. Cushion adjustment requires 50+ operation
cycles for optimal setting. Lubricate rods weekly in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | MICD16X125S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 125mm |
