Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X150S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Cylinder MICD16X150S Technical Details
- Model: MICD16X150S
- Type: Double-rod mini cylinder with air cushion
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 150mm (±0.5mm tolerance)
- Cushioning: Adjustable pneumatic cushion at both ends
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Mounting style: Front/rear flange (MF1) with optional foot mounting (MA1)
- Rod material: Hard chrome-plated steel (C1035)
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Protection class: IP54 (standard), IP67 available on request
- Weight: 0.82kg (with standard accessories)
- Dimensions:
- Length: 228mm (full retracted length)
- Width: 34mm (max flange width)
- Height: 34mm (cylinder tube diameter)
Ultra-compact dual-rod pneumatic actuator featuring built-in air cushioning for smooth end position deceleration. The MICD16X150S's space-saving design (30% smaller than standard cylinders) enables high-precision linear motion in confined spaces. Twin rod configuration prevents rotation during operation and allows equal force output in both directions. Corrosion-resistant construction with integrated mounting slots simplifies installation alignment.
- PCB handling robots in electronics assembly
- Precision lens positioning in optical equipment
- Medical device actuation systems
- Cartesian coordinate pick-and-place units
- Semiconductor wafer transfer mechanisms
Operation guidelines:
Maintain 0.3-1.0 MPa lubrication pressure for optimal seal performance.
Cushion adjustment requires 1/8 turn increments - over-tightening may cause piston rebound.
Use clean dry air with 5-40μm filtration. Vertical mounting preferred for maximum bearing life.
| Property | Property Value |
|---|---|
| sku | MICD16X150S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 150mm |
