Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X160S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Dual Rod Mini Cylinder with Air Cushion - MICD16X160S
- Model: MICD16X160S
- Bore size: 16mm
- Stroke: 160mm
- Cushion type: Adjustable air cushion (both ends)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Rod diameter: 6mm (dual rod)
- Max speed: 500mm/s
- Mounting type: Basic (no foot) with optional accessories:
- MPA: Front flange
- MPB: Rear flange
- MPC: Side lug
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR rubber (-20℃~80℃)
- Weight: 0.68kg (excluding accessories)
- Dimensions (L×W×H):
- Stroke length: 160mm
- Total length: 238mm (160+78 base length)
- Body width: 28mm
- Height with rods: 43mm
- Protection class: IP54 (standard)
A space-saving dual-rod cylinder featuring synchronized movement and precise positioning. The integrated air cushion mechanism reduces impact noise (<65dB) and vibration at stroke ends. Hermetically sealed construction prevents external contamination, with corrosion-resistant treatment for humid environments. Requires 40μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Precision alignment in semiconductor wafer handling
- Dual-axis synchronization in automated packaging lines
- Compact jig positioning for PCB assembly
- Medical device actuator mechanisms
- Cleanroom-compatible automation systems
Installation tip:
Maintain rod parallelism within 0.2mm during mounting. For vertical installations,
use MPA/MPB flanges with locknuts. Lubricate every 3 months (ISO VG32 turbine oil recommended).
Maximum side load: 12N at piston rod end.
| Property | Property Value |
|---|---|
| sku | MICD16X160S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 160mm |
