Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X175
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Air Cushioned Double Rod Mini Cylinder MICD16X175 Specifications
- Model: MICD16X175
- Bore size: 16mm
- Stroke: 175mm
- Operation: Double-acting with adjustable air cushion (both ends)
- Working pressure: 0.05-1.0 MPa
- Cushion stroke: 8±2mm (front/rear)
- Port size: M5x0.8 (standard) / Optional NPT1/8
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel (SUS304)
- Seal type: NBR wear-resistant seals
- Mounting options: Basic type (no accessories) / Multiple mounting brackets available
- Weight: 480±10g (excluding accessories)
- Dimensions:
- Total length: 273mm (at mid-stroke)
- Body width: 28mm
- Height with rods: 44mm
- Mounting hole spacing: 25mm (vertical) × 32mm (horizontal)
- Protection class: IP54 (standard) / IP67 (optional wiper upgrade)
- Lubrication: Pre-lubricated (DOP oil) / Oil-free operation possible
A precision miniaturized linear actuator featuring dual adjustable pneumatic cushions that absorb 95%+ impact energy at stroke ends. The through-rod design enables symmetrical force output and position detection at both ends. Optimized for high-frequency cycling (up to 5 cycles/sec) with <1mm positioning repeatability. Corrosion-resistant construction withstands humid environments.
- PCB board clamping/fixturing in electronics assembly
- Precision part ejection in injection molding machines
- Valve actuation in compact fluid control systems
- Medical device component positioning
- Textile machinery thread control mechanisms
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use flexible couplings for rod-end connections.
For vertical mounting, install cushion adjusters upward. Lubricate rod surfaces monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | MICD16X175 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 175mm |
