Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X175S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Air Cushion Double-Rod Mini Cylinder MICD16X175S Specifications
- Model: MICD16X175S
- Series: MICD (Compact Double-Rod)
- Bore size: 16mm
- Stroke: 175mm (±0.5mm tolerance)
- Cushion type: Adjustable air cushion (both ends)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / Optional NPT1/8
- Mounting type: Basic fixed mounting (accessory brackets available)
- Rod material: Hard chrome-plated stainless steel (SUS304)
- Cylinder tube: Anodized aluminum alloy
- Piston speed: 50–800 mm/s (optimal range 100–500 mm/s)
- Protection rating: IP54 (standard seals) / IP67 (optional wiper upgrade)
- Weight: 580g ±3% (without accessories)
- Dimensions:
- Length: 254mm (full retraction: 175+79mm)
- Width: 32mm (body diameter)
- Height: 32mm (rod centerline to body edge)
A precision double-rod cylinder featuring dual air cushioning for controlled deceleration, designed for applications requiring symmetrical force distribution and minimized lateral deflection. The through-rod design ensures position stability during high-speed reciprocation. Compatible with magnetic sensors (slot width 5.5mm for M9/M12 proximity switches).
- PCB board clamping mechanisms in SMT equipment
- Precision alignment stages in optical lens assembly
- Vertical lifting platforms in pharmaceutical blister packaging
- Tension control systems for textile machinery
- Tool positioning in CNC automatic tool changers
Installation note:
Maintain 0.5–1mm parallel alignment tolerance between rods and load. Lubricate with ISO VG32 turbine oil (1–2 drops per 1 million cycles). For vertical mounting, install rod-down orientation to prevent condensate accumulation.
| Property | Property Value |
|---|---|
| sku | MICD16X175S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 175mm |
