Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X200
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Cylinder MICD16X200 Technical Details
- Model: MICD16X200
- Type: Double-rod mini cylinder with air cushion
- Bore size: 16mm
- Stroke: 200mm (±1.5mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Cushioning: Adjustable pneumatic buffer (both ends)
- Port thread: M5×0.8 (standard) / NPT1/8 optional
- Piston speed: 50–700 mm/s (optimal 200–400 mm/s)
- Ambient temperature: -10℃ to 70℃ (NBR seals)
- Lubrication: Pre-lubricated (relubrication interval ≥3,000km)
- Mounting types: Basic (no accessories) / Multiple foot-mount options
- Rod end: External thread M6×1.0 (both rods)
- Weight: 580g ±2% (without accessories)
- Dimensions:
- Length: 290mm (full extension)
- Body width: 32mm
- Height: 34mm (excluding mounting feet)
- Center-to-center rod spacing: 20mm
- ISO certification: Complies with ISO 6432 standards
Precision-engineered dual-rod cylinder featuring symmetrical force output and position detection readiness. The integrated air cushion minimizes end-impact vibration (adjustable via needle valves), while the anodized aluminum construction ensures corrosion resistance. Dual rod configuration enables stable linear motion ideal for alignment-critical applications.
- PCB board clamping/fixturing in electronics assembly
- Precision glass panel handling systems
- Pharmaceutical capsule sorting mechanisms
- Textile machinery thread tension control
- 3D printer bed stabilization systems
Installation protocol:
For optimal performance, maintain ≤0.03mm/m parallel alignment tolerance between rods and load.
Use rod-end spherical bearings when angular misalignment exceeds ±2°. Lubricate guide rods monthly
with ISO VG32 hydraulic oil in high-cycle applications (>500 cycles/minute).
| Property | Property Value |
|---|---|
| sku | MICD16X200 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <200mm> |
