Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X20S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Miniature Double-Rod Cylinder with Air Cushion (MICD16X20S)
- Model: MICD16X20S
- Bore size: 16mm
- Stroke: 20mm
- Structure: Double-rod, double-acting
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning type: Adjustable air cushion (both ends)
- Port size: M5x0.8 (Rc1/8 adapter optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, CR-Steel piston rod
- Seal material: NBR (Nitrile rubber)
- Mounting options: Basic type, foot-mounted (accessory)
- Weight: 0.32 kg (excluding accessories)
- Dimensions: 90mm(L) × 25mm(W) × 40mm(H) (retracted state)
- Rod diameter: 6mm (both sides)
- Maximum lateral load: 8.2N
- ISO standard: 6432 compliant
Ultra-compact cylinder featuring dual adjustable air cushions for precise end-position deceleration control. The dual-rod design provides symmetrical force output and position detection capability on both ends. Anodized surface treatment enhances corrosion resistance, while the integrated cushion adjustment screws allow fine-tuning of damping performance without disassembly.
- Precision positioning in SMT equipment
- Clamping mechanisms in semiconductor handlers
- Valve actuation in medical analyzers
- Material sorting gates in packaging lines
- Optics adjustment stages in laser systems
Installation tip:
Maintain 0.05mm maximum misalignment during mounting. Lubricate with ISO VG32 turbine oil
during initial setup. For vertical installations, use rod-end support brackets to prevent
piston rod deflection (accessory code: MMF16).
| Property | Property Value |
|---|---|
| sku | MICD16X20S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
