Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X25
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Cylinder MICD16X25 Specifications
- Model: MICD16X25
- Bore size: 16mm
- Stroke: 25mm
- Operating pressure: 0.15-0.8 MPa
- Cushion type: Adjustable air cushion (both ends)
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M6x1.0 (double extended rod)
- Mounting style: Foot/base mount (MF1) or front flange (M9)
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR rubber
- Cushion adjustment: 0-5mm stroke adjustable
- Weight: 0.28kg ±5%
- Dimensions:
- Total length (L): 100mm (at mid-stroke)
- Width (W): 34mm (including mounting tabs)
- Height (H): 34mm (barrel diameter)
- Repeat positioning accuracy: ±0.1mm
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (oil-free operation possible)
- IP rating: IP54 (standard) / IP67 (optional wiper upgrade)
This dual-rod mini cylinder features integrated air cushions and symmetrical force output, engineered for precision linear motion in space-constrained automation. The twin-rod design eliminates rotational torque during operation, making it ideal for alignment-critical applications. Optimized for 500,000+ cycle durability with <0.5mm cushion dead zone.
- PCB handling robots - chip placement & testing
- Medical device assembly - syringe plunger actuation
- Semiconductor wafer processing - vacuum chuck positioning
- Packaging lines - simultaneous lid closing mechanisms
- Textile machinery - precision thread tension control
Installation protocol:
Maintain 0.5mm minimum lateral clearance between rods and load.
For vertical mounting, use locking nuts on both piston rod ends.
Buffer adjustment requires 0.5Nm torque limit - turn clockwise
to decrease cushioning effect.
| Property | Property Value |
|---|---|
| sku | MICD16X25 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <25 mm> |
