Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X40
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Compact Air Cylinder MICD16X40 Specifications
- Model: MICD16X40
- Bore size: 16mm
- Stroke: 40mm
- Operation type: Double-acting with air cushion
- Operating pressure: 0.05-0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Cushion adjustment: Adjustable buffer (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Rod thread: M5x0.8 external thread
- Mounting types: Basic type (no mount) / Foot-mounted (MFI)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 0.28kg (basic type) / 0.32kg (with foot mount)
- Dimensions:
- Body diameter: Φ32mm
- Total length: 108mm (at mid-stroke)
- Mounting hole spacing: 25mm (foot mount version)
- Rod extension length: 24mm (each side)
- ISO standard: 6432 compliant
- Protection class: IP54 (standard seals)
Ultra-compact double-rod cylinder featuring symmetrical force output and space-saving design. The integrated air cushion mechanism minimizes end-impact noise while allowing precise stroke adjustment. Dual rod configuration provides excellent lateral load capacity and improved alignment stability. Special anti-rotation design prevents piston rod spinning during operation.
- Precision positioning in SMT equipment
- Clamping mechanisms in semiconductor handlers
- Material transfer in 3C product assembly lines
- Actuation systems in cleanroom environments
- Automated test fixture actuation
Installation note:
For optimal performance, maintain 0.5mm minimum clearance between rods and adjacent components.
Lubricate with ISO VG32 turbine oil (1-2 drops per port) during initial installation.
Cushion adjustment requires 2mm hex key (included with factory packaging).
| Property | Property Value |
|---|---|
| sku | MICD16X40 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <40mm> |
