Airtac MICD Air Cushion Double Rod Mini Cylinder MICD16X40S
2. Integrated fixed cushion rings on front/rear end caps reduce impact shock during directional changes;
3. Multiple rear cap configurations simplify installation flexibility;
4. Riveted hybrid enclosure structure securely joins end caps to stainless steel cylinder barrel;
5. Stainless steel piston rod and barrel construction ensures reliable operation in mildly corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available for customized solutions.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MICD
AirTAC MICD Series Dual Rod Mini Cylinder with Air Cushion - MICD16X40S
- Model: MICD16X40S
- Bore size: 16mm
- Stroke: 40mm
- Operation: Double-acting
- Cushion type: Adjustable air cushion (both ends)
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston speed: 50-700 mm/s
- Mounting type: Basic (no built-in mounts)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (standard) / PU optional
- Protection class: IP54
- Weight: 0.28kg ±2%
- Dimensions (L×W×H):
- Basic body: 97mm(L) × 16mm(Ø) × 28mm(mounting width)
- Full extension: 97mm + 40mm stroke
- Rod diameter: 6mm (dual rods)
Ultra-compact dual-rod cylinder featuring synchronized output motion and precision air cushion adjustment. The MICD series combines a 30% smaller footprint than standard cylinders with hardened anodized aluminum construction for wear resistance. Dual rod design eliminates rotation during operation, ideal for precision alignment tasks. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- PCB component insertion machines
- Micro-dispensing systems in semiconductor manufacturing
- Optical lens positioning mechanisms
- Lab automation sample handling arms
- Compact gripper actuation in collaborative robots
Maintenance tip:
Adjust cushion screws while observing motion - optimal setting achieved when piston decelerates smoothly without impact noise. Relubricate every 50km of cumulative travel. Do not exceed 0.05 MPa when using in vacuum applications.
| Property | Property Value |
|---|---|
| sku | MICD16X40S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <40mm> |
