Airtac MICJ Adjustable Mini Cylinder MICJ16X125-50
$47.89
Regular price
$55.39
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MICJ16X125-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with ISO 6432 standard (Φ8-25mm);
2、Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3、Versatile rear cover configurations enhance installation flexibility;
4、Crimped hybrid enclosure structure ensures secure connection between covers and stainless steel cylinder barrel;
5、Stainless steel piston rod and barrel construction provides corrosion resistance for harsh environments;
6、Multiple cylinder specifications and mounting accessories available for customer selection.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MICJ
Installation tip:
For optimal performance, maintain 0.5-1mm clearance between cylinder body
and machine frame to prevent binding. Use Loctite 243 on adjustment screws
after stroke setting. Lubricate with ISO VG32 turbine oil if operating below 2℃.
2、Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3、Versatile rear cover configurations enhance installation flexibility;
4、Crimped hybrid enclosure structure ensures secure connection between covers and stainless steel cylinder barrel;
5、Stainless steel piston rod and barrel construction provides corrosion resistance for harsh environments;
6、Multiple cylinder specifications and mounting accessories available for customer selection.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MICJ
AirTAC MICJ Adjustable Miniature Cylinder MICJ16X125-50 Technical Details
- Series: MICJ (Compact Adjustable Stroke)
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 125mm (adjustable ±2mm via external screws)
- Operating pressure: 0.05-1.0 MPa
- Port size: M5x0.8 (standard) with optional NPT1/8 adapters
- Cushioning: Adjustable rubber buffers at both ends
- Mounting type: Basic (no flange) with axial mounting holes
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seals: NBR (Nitrile) standard, optional FKM/Viton
- Ambient temperature: -20℃ to 80℃ (NBR version)
- Max speed: 500mm/s (with cushioning engaged)
- Weight: 0.45kg (excluding accessories)
- Dimensions:
- Body diameter: 23mm
- Total length: 202mm (stroke 125mm + end caps)
- Rod end thread: M6x1.0 (male)
- Protection class: IP54 (standard wiper seal)
Ultra-compact linear actuator featuring stroke micro-adjustment capability (±2mm) through twin locking nuts. Precision-ground rod with integrated shock absorption prevents chatter in high-cycle applications. Optional magnetic piston version (MICJ16X125-50-M) enables position sensing.
Ideal For:
- PCB assembly pick-and-place machines
- Pharmaceutical blister packaging systems
- Semiconductor wafer handling robots
- Automated test equipment positioners
- Compact jig clamping mechanisms
Installation tip:
For optimal performance, maintain 0.5-1mm clearance between cylinder body
and machine frame to prevent binding. Use Loctite 243 on adjustment screws
after stroke setting. Lubricate with ISO VG32 turbine oil if operating below 2℃.
| Property | Property Value |
|---|---|
| sku | MICJ16X125-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | 125mm |
