Airtac MKJ Adjustable Cylinder MKJ10X25-30
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Adjustable Cylinder MKJ10X25-30 Technical Details
- Model: MKJ10X25-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 10mm (precision-ground inner diameter)
- Standard stroke: 25mm (adjustable range: ±15mm)
- Total stroke adjustment: 0-30mm via external stop screws
- Operating pressure: 0.05-0.9 MPa
- Port size: M5×0.8 (standard) with dual cushioning
- Mounting style: Fixed type with front flange (FC series compatible)
- Temperature range: -10℃ to 80℃
- Rod material: Stainless steel (SUS304) with hard chrome plating
- Tube material: Aluminum alloy (anodized surface)
- Seal type: HNBR seals with wear-resistant ring
- Weight: 0.28kg (excluding accessories)
- Dimensions: 98mm(L) × 42mm(W) × 42mm(H) (max extended length)
Precision micro cylinder featuring unique mechanical stroke adjustment mechanism with ±15mm fine-tuning capability. The dual locking nuts ensure stable position retention under vibration. Integrated cushioning reduces end-impact noise to below 70dB. Compatible with ISO 6432 mounting accessories.
- PCB board clamping mechanisms in SMT machines
- Precision dosage control in pharmaceutical packaging
- Lens positioning systems for optical manufacturing
- Micro-part ejection in watch assembly automation
- Variable stroke control for semiconductor test handlers
Operation tip:
Always perform stroke adjustment with air pressure disconnected.
Apply silicone grease (ISO VG10 grade) monthly on adjustment screws
for smooth operation. Avoid exceeding 90% of max stroke during fine-tuning.
| Property | Property Value |
|---|---|
| sku | MKJ10X25-30 |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
