Airtac MKJ Adjustable Cylinder MKJ10X25-30S
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Series Adjustable Stroke Cylinder MKJ10X25-30S Technical Details
- Model Code: MKJ10X25-30S
- Type: Compact adjustable stroke double-acting cylinder
- Bore size: Ø10mm (precision honed tube)
- Stroke range: 1-25mm (externally adjustable via screw mechanism)
- Max operating pressure: 0.02-1.0 MPa
- Cushioning: Rubber buffer + adjustable needle valve (both ends)
- Mounting style: Female threaded rod (M5×0.8)
- Temperature range: -10℃ to 70℃ (NBR seals)
- Port size: M5×0.8 (standard) with optional PT1/8 adaptor
- Rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Weight: 128g ±3% (without accessories)
- Dimensions:
- Body length: 60mm (fixed)
- Stroke-adjusted length: 65-85mm (min-max)
- Width: 25mm (hexagonal body)
- Height: 25mm (including rod end)
Ultra-compact precision cylinder with stepless stroke adjustment capability, featuring dual anti-rotation design for stable linear motion. The chrome-plated piston rod integrates a dust-resistant scraper, while the 30S suffix indicates special high-cycle seals rated for >5 million operations. Requires ISO 8573-1 class 3 lubricated air (or oil mist lubrication).
- Precision clamping in PCB component insertion machines
- Micro-feeding mechanisms for semiconductor wafer handling
- Valve actuation in medical fluid dispensing systems
- Position adjustment in optical lens alignment equipment
- Sorting gate control in high-speed packaging lines
Installation protocol:
Use locknut (not included) to secure adjustment screw after calibration.
Maximum side load: 2.5N. Lubricate through air port (ISO VG32 equivalent)
every 50km of cumulative stroke. Avoid angular misalignment >0.5°.
| Property | Property Value |
|---|---|
| sku | MKJ10X25-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
