Airtac MKJ Adjustable Cylinder MKJ10X30-10S
$56.05
Regular price
$63.55
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MKJ10X30-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
Maintenance advisory:
Lubricate with ISO VG32 hydraulic oil or equivalent monthly.
Maximum side load capacity: 5N. For vertical mounting,
use counterbalance valve when handling suspended loads.
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Adjustable Cylinder MKJ10X30-10S Technical Specifications
- Model Code Breakdown: MKJ10X30-10S
- MKJ: Adjustable stroke mini cylinder series
- 10: Bore size Ø10mm
- 30: Maximum stroke length 30mm
- 10S: Single-rod double acting with adjustable stroke mechanism
- Operating pressure: 0.05–0.8 MPa (7-116 PSI)
- Ambient temperature: -20℃ to 80℃ (non-freezing conditions)
- Cushioning: Built-in rubber buffers + external stroke adjuster
- Stroke adjustment range: 0–30mm (continuous fine-tuning via locking screw)
- Mounting style: Standard AF (front flange) with M4 threaded mounting holes
- Port size: M5x0.8 (push-in fitting compatible)
- Rod end: M4 threaded female
- Material:
- Barrel: Aluminum alloy hard anodized
- Piston rod: Stainless steel (SUS304)
- Seals: NBR + special polyurethane blend
- Weight: 0.23kg (with standard accessories)
- Dimensions:
- Extended length: 100±0.5mm
- Retracted length: 70±0.5mm
- Body width: 25mm
- Mounting flange height: 12mm
- ISO standard: Compliant with ISO 6432 (miniature cylinders)
- Protection rating: IP54 (standard seals)
Precision micro cylinder featuring patented stroke adjustment mechanism with ±0.5mm repeatability. The dual-cushion design reduces end-impact noise to <65dB. Anti-rotation guide slots ensure stable linear motion. Optional magnetic piston version (add "-M" suffix) available for position sensing.
Industrial Applications:
- PCB board clamping/fixturing in electronics manufacturing
- Precision dosage control in pharmaceutical dispensing machines
- Micro-part ejection systems in high-speed stamping presses
- Z-axis position adjustment in optical lens alignment equipment
- Tension control for thin film materials in packaging lines
Maintenance advisory:
Lubricate with ISO VG32 hydraulic oil or equivalent monthly.
Maximum side load capacity: 5N. For vertical mounting,
use counterbalance valve when handling suspended loads.
| Property | Property Value |
|---|---|
| sku | MKJ10X30-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
