Airtac MKJ Adjustable Cylinder MKJ10X5-10S
$45.35
Regular price
$52.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MKJ10X5-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
Installation tip:
For optimal performance, mount with 0.5-1mm clearance between adjustment screw
and stopper plate. Lubricate with ISO VG32 hydraulic oil during maintenance cycles.
Avoid lateral force exceeding 5N on piston rod.
2. Multiple mounting configurations for simplified installation;
3. Supports parallel cylinder mounting to optimize space utilization;
4. Precision-guided piston rod eliminates need for external lubrication;
5. Integrated piston rod locking block prevents rotation during operation;
6. Extensive range of models and specifications for diverse applications;
7. Optional high-temperature seals available for 0-150℃ operating range (Optional).
Category: Adjustable Cylinders | Brand: AirTAC | Series: MKJ Series
AirTAC MKJ Adjustable Cylinder MKJ10X5-10S Technical Details
- Model: MKJ10X5-10S
- Type: Compact adjustable stroke double-acting cylinder
- Bore size: 10mm
- Stroke: 5mm (adjustable via mechanical stopper)
- Operating pressure: 0.05–0.9 MPa
- Adjustment range: ±2mm stroke fine-tuning
- Cushioning: Rubber buffer + adjustable damping
- Mounting style: Basic type (accessory brackets available)
- Operating temperature: -10℃ to 70℃
- Material: Aluminum alloy barrel, CRMo steel piston rod
- Port size: M5x0.8 (standard)
- Protection class: IP54 (standard sealing)
- Weight: 0.23kg
- Dimensions: 56mm(L) × 25mm(W) × 25mm(H)
Precision micro-cylinder featuring patented stroke adjustment mechanism with locking nut. The chromium-plated piston rod resists side loads, while the dual cushioning system minimizes end-impact noise. Requires ISO 8573-1 class 3 or cleaner compressed air.
Ideal For:
- PCB component insertion machines
- Precision lens positioning in optical equipment
- Pharmaceutical blister packaging systems
- Semiconductor wafer handling robots
- Textile machine thread tension control
Installation tip:
For optimal performance, mount with 0.5-1mm clearance between adjustment screw
and stopper plate. Lubricate with ISO VG32 hydraulic oil during maintenance cycles.
Avoid lateral force exceeding 5N on piston rod.
| Property | Property Value |
|---|---|
| sku | MKJ10X5-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
