Airtac P-3V-M Cover Plate P-3V100M-R1
2、Features centralized intake/exhaust ports and unified wiring layout to streamline troubleshooting processes and enhance maintenance efficiency;
3、Modular design with exceptional flexibility and scalability, allowing arbitrary combination or expansion of connected directional control valves according to operational requirements;
Category: Cover Plates , Brand: Airtac , Series: P-3V-M
AirTAC P-3V-M Cover Plate P-3V100M-R1 Technical Details
- Model: P-3V100M-R1
- Component Type: Valve Cover Plate (Accessory)
- Compatible Series: P-3V-M solenoid valves
- Material: Anodized aluminum alloy (black finish)
- Mounting Type: Side-mounted modular plate
- Pressure Rating: Compatible with 0.05-1.0 MPa systems
- Temperature Range: -20℃ to 80℃
- Surface Hardness: HV400±50
- Seal Material: NBR rubber (oil-resistant)
- Weight: 0.32 kg ±5%
- Dimensions: 100mm(L) × 30mm(W) × 15mm(H)
- Mounting Screws: M3×8 stainless steel (included)
- Protection Level: IP54 when installed
Durable cover plate designed for modular protection of P-3V-M series solenoid valve banks. Features precision-machined alignment pins for leak-proof connections between valve bodies. The black oxidation surface treatment provides corrosion resistance in humid environments. Includes pre-installed O-rings for immediate installation.
- Multi-valve manifold assemblies in packaging machinery
- Pneumatic control cabinet protection
- Dustproof sealing for automated production lines
- Modular pneumatic systems in semiconductor equipment
- Mobile hydraulic/pneumatic hybrid platforms
Installation Guidelines:
Apply thread locker on mounting screws (0.2N·m torque recommended).
Replace O-rings every 5,000 operating hours or 2 years.
Compatible with ISO 15407-1 standard valve bodies.
| Property | Property Value |
|---|---|
| sku | P-3V100M-R1 |
