Airtac P-3V-M Cover Plate P-3V300M-R1
2、Features centralized intake/exhaust ports and unified wiring layout to streamline troubleshooting processes and enhance maintenance efficiency;
3、Modular design with exceptional flexibility and scalability, allowing arbitrary combination or expansion of connected directional control valves according to operational requirements;
Category: Cover Plates , Brand: Airtac , Series: P-3V-M
AirTAC P-3V-M Cover Plate P-3V300M-R1 Technical Specifications
- Model: P-3V300M-R1
- Type: Valve manifold cover plate
- Material: Aluminum alloy 6063-T5
- Compatible series: P-3V series solenoid valves
- Surface treatment: Anodized (silver finish)
- Weight: 680±10g
- Dimensions: 300mm(L) × 22mm(W) × 34mm(H)
- Mounting hole spacing: 25mm centers
- Max operating pressure: 1.0 MPa
- Temperature range: -10℃ to 80℃
- Surface hardness: HV 12±2
- Flatness tolerance: ≤0.1mm/m
- Corrosion resistance: 96hrs salt spray test passed
Heavy-duty manifold cover designed for multi-valve stacking in pneumatic systems. Features precision-machined sealing surfaces with dual O-ring grooves (NBR material included). Includes integrated mounting slots compatible with DIN rail systems and anti-vibration rubber pads for industrial environments.
- Modular pneumatic control stations
- Automated assembly line manifolds
- Plastic injection molding machines
- Automotive brake system clusters
- Food processing pneumatic circuits
Installation note:
Apply thread sealant (LOCTITE 577 recommended) on mounting screws.
Torque limit: 1.2-1.5N·m. Avoid overtightening to prevent surface deformation.
| Property | Property Value |
|---|---|
| sku | P-3V300M-R1 |
