Airtac P-ACQD Repair Kit P-ACQD20-R2
AirTAC P-ACQD20-R2 Repair Kit Technical Details
- Model: P-ACQD20-R2
- Compatible Series: ACQ20, ACQ20D (dual rod), ACQ20B (basic type)
- Seal Material: Polyurethane (PU) & Nitrile Rubber (NBR) combination
- Spring Material: Stainless steel SUS304
- Bearing Material: Self-lubricating engineering plastic
- Temperature Range: -20℃ to 80℃
- Pressure Rating: 0.05-1.0 MPa
- Package Contents:
- Main seal ring (x2)
- Piston seal ring (x2)
- Wiper seal (x2)
- Spring set (x4)
- Spacer shims (x4)
- Guide ring (x4)
- Hex socket screws (x4)
- Special lubricant (3g sachet)
- Weight: 0.28 kg (entire kit)
- Package Dimensions: 150mm(L) × 100mm(W) × 30mm(H)
- Storage Humidity: ≤85% RH (non-condensing)
- Shelf Life: 5 years in original packaging
Comprehensive maintenance solution for ACQ20 series cylinders, engineered for wear compensation and leak prevention. The precision-matched components restore original performance parameters while maintaining 98%+ compatibility with factory specifications. Kit includes corrosion-inhibited parts for immediate use.
- Preventive maintenance in high-cycle automation lines (300,000+ cycles)
- Overhaul of contaminated cylinders in food processing machinery
- Field repairs for hydraulic hybrid systems using ISO VG32 fluid
- Restoration of vertically mounted cylinders in CNC equipment
Installation protocol:
Clean cylinder bore with non-woven cloth before assembly. Apply included
lubricant to all sliding surfaces. Torque screws to 1.2N·m ±10% using
cross pattern tightening sequence. Perform 5-10 test strokes before reloading.
