Airtac P-ACQD Repair Kit P-ACQD40-R2
AirTAC P-ACQD40-R2 Repair Kit Technical Details
- Model: P-ACQD40-R2
- Compatible series: ACQD40 standard cylinder series
- Package contents:
- Piston seal (PU material) x2
- Rod seal (NBR) x2
- Buffer seal (PU) x2
- Wiper seal (polyurethane) x1
- O-rings (NBR 70°):
- 8mm ID x1.5mm CS (Qty:4)
- 15mm ID x2mm CS (Qty:2)
- Lubrication grease sachet (3g silicone-free)
- Temperature tolerance: -20℃ to 80℃
- Pressure rating: 0.05-1.0 MPa
- Storage life: 5 years in original packaging
- Package weight: 0.52 kg ±5%
- Dimensions: 210mm(L) × 165mm(W) × 45mm(H)
- Packaging material: Anti-static multilayer barrier pouch
- Certification: RoHS 3 compliant
Complete maintenance solution for ACQD40 pneumatic cylinders, containing wear-resistant polyurethane and oil-resistant NBR seals. Features precision-molded components with ±0.02mm dimensional tolerance. Kit includes factory-grade lubricant formulated for high-cycle applications (50,000+ strokes).
- Preventive maintenance cycles (recommended every 500 operating hours)
- Restoration of cylinders showing air leakage >0.5 L/min
- Overhaul after contamination incidents (e.g., particulate ingress)
- Adaptation for special media (requires material compatibility verification)
Installation protocol:
Disassemble cylinder using JIS B 4634-1994 standard tools. Clean components with
non-petroleum solvent before assembly. Apply included grease to seal grooves
using flat-end tool. Torque end bolts to 12-15 N·m.
Contains small parts - keep away from
ESD-sensitive areas. Use within 48 hours after opening moisture-proof packaging.
