Airtac P-MDD Repair Kit P-MDD32-R1
AirTAC P-MDD32-R1 Repair Kit Technical Details
- Repair kit code: P-MDD32-R1
- Compatible series: PMDD standard rod cylinders (32mm bore)
- Package contents: 38 components including seals, wipers, O-rings, backup rings
- Material composition:
- Primary seals: Polyurethane (AU)
- Secondary seals: Nitrile rubber (NBR)
- Wipers: Glass-filled PTFE
- Backup rings: Reinforced polyoxymethylene
- Temperature tolerance: -30℃ to 100℃ (intermittent peak 120℃)
- Pressure rating: 0.05-1.2 MPa (optimized for 0.3-0.8 MPa operation)
- Chemical resistance: Compatible with ISO VG32 hydraulic oil & most industrial lubricants
- Weight: 225g ±5% (including anti-static packaging)
- Package dimensions: 180mm(L) × 95mm(W) × 25mm(H)
- Shelf life: 5 years in unopened moisture-proof packaging
Complete overhaul solution for PMDD series cylinders, containing factory-grade replacement components to restore original performance parameters. Features wear-compensating seal designs and anti-extrusion rings for high side-load applications. Kit includes specialized installation tools: nylon drift pins and seal insertion cones.
- Cylinder rebuilds after 5,000km stroke accumulation
- Seal replacement following fluid contamination incidents
- Preventive maintenance during annual shutdowns
- Overhaul of cylinders showing ≤85% output efficiency
Service protocol:
Disassemble in ISO Class 7 clean environment. Lubricate all seals with
AirTAC PAG-32 assembly grease before installation. Torque end caps to
28-32 N·m using crisscross pattern.
| Property | Property Value |
|---|---|
| sku | P-MDD32-R1 |
| Bore Diameter | <32 mm> |
