Airtac P-SDAT Repair Kit P-SDAT63-R2
Category: Cylinder Seal Kits
Brand: AirTAC Automation Group
Series: P-SDAT Series
Description:
This OEM repair kit contains complete sealing components for P-SDAT series pneumatic cylinders, including O-rings, guide rings, wear rings, piston seals, and rod seals. Engineered to factory specifications using nitrile (NBR) or polyurethane (PU) compounds for optimal chemical resistance and durability. Ensures proper cylinder rebore tolerance restoration and leakage prevention. Recommended for preventive maintenance or overhaul of ISO 15552 compliant pneumatic actuators. Kit contains all necessary sealing elements for standard cylinder maintenance excluding piston rods and cylinder barrels.
AirTAC P-SDAT63-R2 Repair Kit Technical Details
- Full Model Code: P-SDAT63-R2
- Compatible Series: SDAT63 standard cylinder models
- Package Contents:
- Piston seals (NBR) ×2
- Rod seals (PU) ×2
- Wear rings (PTFE composite) ×4
- O-rings (NBR 70°) ×6 (sizes: 3×1.5mm, 5×2mm, 8×2mm)
- Springs (SUS304 stainless) ×2
- Grease (Molykote EM-30L) 5g sachet
- Material Hardness: 90±2 Shore A (seals)
- Temperature Range: -20℃ to +80℃ (continuous operation)
- Pressure Rating: 0.05-1.5 MPa
- Weight: 215g ±5% (including packaging)
- Dimensions: 120mm(L) × 85mm(W) × 25mm(H) (flat blister pack)
- Storage Humidity: ≤75% RH (non-condensing)
- Shelf Life: 5 years in original sealed packaging
Comprehensive maintenance kit for SDAT63 series compact cylinders, containing wear-resistant components engineered to OEM specifications. Features precision-molded seals with reinforced lip geometry for enhanced blowout resistance. Includes factory-grade lubricant optimized for pneumatic systems.
- Recommended replacement interval: 5 million cycles or 2 years (whichever comes first)
- Critical for restoring cylinder efficiency in high-duty applications
- Mandatory after cylinder disassembly for contamination removal
- Used in conjunction with AirTAC S-500 series guide units
- Clean cylinder bore with isopropyl alcohol before installation
- Apply included grease to seal grooves using dedicated tooling
- Use torque-controlled wrench for end cap reassembly (3.5N·m max)
- Perform 50 test cycles before returning to service
Warning:
Do not mix seal materials from different batches. Always replace all seals simultaneously
to prevent uneven compression. Compatible only with AirTAC SDAT63-B/-C variants.
