Airtac P-SG Repair Kit P-SG250-R1
AirTAC P-SG250-R1 Cylinder Repair Kit Technical Details
- Model: P-SG250-R1
- Compatible series: SG series standard cylinders (SG250 specific)
- Seal materials: NBR (Nitrile) + PU (Polyurethane) hybrid components
- Temperature range: -20℃ to 80℃ (continuous operation)
- Pressure rating: 0.05-1.0 MPa (optimized for 0.3-0.8 MPa typical use)
- Kit contents:
- Piston seals (2x)
- Rod seals (2x)
- Wiper seals (2x)
- O-rings (multiple sizes)
- Backup rings
- Specialty lubricant (5g tube)
- Spring retainers
- Weight: 220g ±5% (including packaging)
- Dimensions: 160mm(L) × 105mm(W) × 25mm(H) (flat-packed design)
- Storage conditions: 5-35℃ in dry environment (5-year shelf life unopened)
Complete maintenance solution for SG250 pneumatic cylinders, featuring wear-resistant composite seals that reduce friction by 30% compared to standard kits. The precision-molded components maintain original equipment tolerances (±0.01mm) for leak-free operation. Includes factory-grade silicone-free lubricant compatible with ISO 8573-1 air quality standards.
- Preventive maintenance: Replace every 500,000 cycles in continuous operation
- Corrective maintenance: Address air leakage >0.5L/min under 0.5MPa
- Ideal for:
- High-cycle automation lines (e.g., pick-and-place systems)
- Food processing equipment requiring FDA-compliant seals
- Low-friction applications in cleanroom environments
Installation protocol:
Clean cylinder bore with alcohol wipe (included), apply lubricant in cross-hatch pattern,
and perform 10-15 manual strokes before pressurization. Torque end bolts to 12-15N·m.
| Property | Property Value |
|---|---|
| sku | P-SG250-R1 |
