Airtac P-TN Repair Kit P-TN20-R1
AirTAC P-TN20-R1 Repair Kit Technical Details
- Model: P-TN20-R1
- Compatible Series: TN20 cylinder series
- Package Contents:
- Piston seals (NBR) ×2
- Rod seals (PU) ×2
- Wear rings (POM) ×4
- O-rings (NBR) ×6 (various sizes)
- Cushion seals (PU) ×2
- Backup rings (PTFE) ×2
- Material Compatibility:
- Temperature range: -20℃ to 80℃
- Pressure rating: ≤1.0 MPa
- Fluid compatibility: Air (oil mist lubricated)
- Weight: 200g ±5g (including packaging)
- Dimensions: 120mm(L) × 80mm(W) × 25mm(H)
- Storage Requirements:
- Keep in original sealed bag
- Store in dark, dry environment below 40℃
- Shelf life: 5 years from manufacture date
Complete maintenance solution for TN20 series cylinders, containing all critical wear components for full pneumatic seal replacement. Features oil-resistant NBR and high-durability PU materials optimized for 5 million cycle operations. Kit includes anti-extrusion rings to prevent seal deformation under impact loads.
- Preventive maintenance in automated assembly lines
- Overhaul of pneumatic clamping units
- Seal replacement after 10,000 operating hours
- Emergency repair of leaking cylinders in packaging machinery
- Retrofitting legacy TN20 cylinders with upgraded seals
Maintenance protocol:
Clean cylinder bore with alcohol before installation.
Apply silicone grease (ISO VG 1) to seals.
Replace all components simultaneously for optimal performance.
| Property | Property Value |
|---|---|
| sku | P-TN20-R1 |
