Airtac P-TR Repair Kit P-TR6-R1
AirTAC P-TR6-R1 Repair Kit Technical Details
- Model compatibility: Designed for PTR series valves (PTR6/PTR6D/PTR6S)
- Kit contents:
- Spool valve Ø6mm (x2)
- NBR O-rings (5×1.5mm, x4)
- PTFE backup rings (x2)
- Stainless steel spring 304SS
- Wear-resistant guide ring (x2)
- Dust seal (polyurethane)
- Material specifications:
- Seals: 70±5 Shore A NBR (oil-resistant)
- Metal components: Carbon steel with zinc-nickel plating
- Temperature tolerance: -30℃ to 100℃ (continuous)
- Weight: 215g ±5g (including packaging)
- Dimensions: 120mm(L) × 85mm(W) × 25mm(H) (blister pack)
- Storage requirements: 5-35℃ dry environment, avoid ozone exposure
- Compatibility fluids: Air, inert gases, and light hydraulic oils (ISO VG32 or lower)
- Certification: RoHS compliant
Complete maintenance solution for PTR series pneumatic valves, containing all wear-prone components for full rebuild. Features oil/fuel-resistant seals and anti-corrosion treated metal parts, ensuring 5,000+ cycle durability post-repair. Kit includes specialized assembly grease (3g tube) for proper seal installation.
- Preventive maintenance during annual equipment overhaul
- Restoring leaky valves in packaging line pneumatic systems
- Field repair of CNC machine tool clamping mechanisms
- Rebuilding valves exposed to high-cycle operations (＞1M cycles)
Service advisory:
Replace entire seal set simultaneously. Use torque-limited tools (0.5-0.7Nm)
during reassembly to prevent component deformation. Perform pressure decay test
(0.6MPa for 15min) post-installation.
| Property | Property Value |
|---|---|
| sku | P-TR6-R1 |
