Airtac PBD Pen-shaped Double Rod Cylinder PBD10X150S
$29.53
Regular price
$37.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PBD10X150S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
PBD Series Double-Rod Cylinders (AirTAC)
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
Installation note:
Maintain parallel alignment within 0.05mm/m during mounting. Use flexible couplings for rod-end connections.
For vertical installations, add mechanical brake modules (AMBC2 series recommended).
Critical parameters:
Max thrust 6.28N at 0.5MPa (extend/retract equally).
Do not exceed 500mm/s piston speed. Lubricate every 50km travel distance.
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD10X150S Pen-Type Double Rod Cylinder Specifications
- Model: PBD10X150S
- Type: Double-acting, dual rod pen cylinder
- Bore size: Ø10mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Piston rod material: SUS304 stainless steel (Ø4mm x 2 rods)
- Cylinder tube: Hard anodized aluminum alloy
- Cushioning: Adjustable air cushion at both ends
- Seals: NBR (nitrile) standard, optional FKM/Viton
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 adaptor compatible)
- Weight: 0.25kg (excluding accessories)
- Dimensions: 200mm(L) × 20mm(Ø) × 20mm(rod end protrusion)
- Mounting: Front flange (standard), optional side/tandem mounts
- Repeat accuracy: ±0.1mm
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
Ultra-compact dual-rod cylinder with symmetrical force output, featuring anti-rotation design for precision linear motion. The through-rod configuration maintains position stability during sudden pressure drops. Chrome-plated piston rods include scratch-resistant coating (3-5μm thickness) for dust-sealed applications.
Typical Applications:
- PCB board clamping/fixturing systems
- Micro-dispensing valve actuation
- Optical lens alignment mechanisms
- 3D printer Z-axis synchronization
- Laboratory automation sample handlers
Installation note:
Maintain parallel alignment within 0.05mm/m during mounting. Use flexible couplings for rod-end connections.
For vertical installations, add mechanical brake modules (AMBC2 series recommended).
Critical parameters:
Max thrust 6.28N at 0.5MPa (extend/retract equally).
Do not exceed 500mm/s piston speed. Lubricate every 50km travel distance.
| Property | Property Value |
|---|---|
| sku | PBD10X150S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | 150mm |
