Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10S
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X10S Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X10S
- Type: Double-acting, dual rod cylinder
- Bore size: 6mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Elastic buffer (both ends)
- Mounting style: Foot-mounted (Standard) / Front flange optional
- Port size: M3x0.5 (Dual ports on both ends)
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.12kg ±5%
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H) (Excluding rods)
- Rod diameter: 2.5mm (Per rod)
- Max theoretical thrust: 4.24N @0.5MPa
- ISO standard: 6432 compliant (Compact series)
A precision miniature cylinder featuring synchronized dual-rod movement in an ultra-compact 6mm bore design. The hardened aluminum construction and dual stainless steel rods ensure precise linear motion with minimal deflection. Integrated cushioning prevents end-impact vibration, making it ideal for high-cycle applications. Requires 40μm filtered air and ISO VG32 turbine oil lubrication (optional oil-free operation available).
- PCB component insertion machines
- Optical lens positioning systems
- Semiconductor wafer handling
- Laboratory automation grippers
- Medical device micro-actuation
- 3D printer filament tensioners
Installation note:
Maintain parallel rod alignment during mounting. For vertical installations,
use speed controllers to prevent piston slam. Maximum side load: 0.3N.
Lubricate every 500km travel distance in normal operating conditions.
| Property | Property Value |
|---|---|
| sku | PBD6X10S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | <10mm> |
