Airtac PBD Pen-shaped Double Rod Cylinder PBD6X15
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X15 Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X15
- Type: Double-acting pen-type cylinder
- Bore size: 6mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber buffer (both ends)
- Mounting style: Front flange/Foot mount/Lateral lug
- Port size: M5x0.8 (standard)
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 0.12kg ±2%
- Dimensions: 45mm(L) × 15mm(W) × 15mm(H) (excluding rods)
- Rod diameter: 2.5mm
- Max theoretical thrust: 25.4N (at 0.63MPa)
- Protection rating: IP54
A precision miniaturized actuator featuring symmetrical dual-rod design for enhanced stability in confined spaces. The chrome-plated piston rods and corrosion-resistant construction enable reliable performance in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 cleanliness.
- PCB board clamping mechanisms
- Micro-precision valve actuation
- Optical lens positioning systems
- Laboratory automation equipment
- Medical device linear motion control
- Semiconductor wafer handling
Installation note:
Lubricate through air port (VG68 oil mist recommended) before initial use.
Maintain 0.5mm minimum lateral clearance during alignment.
Avoid lateral loads exceeding 1.5N to prevent rod bending.
| Property | Property Value |
|---|---|
| sku | PBD6X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | <15mm> |
