Airtac PBD Pen-shaped Double Rod Cylinder PBD6X15S
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X15S Pen-Type Double-Acting Cylinder Specifications
- Model: PBD6X15S
- Type: Pen-style double rod double-acting cylinder
- Bore size: 6mm
- Stroke: 15mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer (both ends)
- Port size: M5x0.8 threaded
- Mounting: Dual M4 threaded holes (rod & end cover sides)
- Material: Aluminum alloy barrel, stainless steel rod
- Seal material: NBR (standard), optional FKM
- Repeat accuracy: ±0.2mm
- Piston speed: 50–800 mm/s
- Weight: 110g ±5%
- Dimensions: 72mm(L) × 20mm(W) × 20mm(H)
- Durability: 5,000km (ISO standard test)
- Sensor installation: Compatible with magnetic switches (M5x0.8 threaded holes)
Ultra-compact dual-rod cylinder featuring symmetrical force output and space-saving design. The chrome-plated piston rod provides corrosion resistance, while the dual guiding shafts ensure precise linear motion. Requires ISO VG32 or equivalent hydraulic oil lubrication for optimal performance.
- Precision alignment in PCB assembly robots
- Simultaneous clamping mechanisms in micro-molding machines
- Optical lens positioning systems
- Bilateral actuation in semiconductor wafer handlers
- Laboratory sample tray indexing systems
Installation note:
Maintain parallel alignment of dual rods during assembly. Use flexible couplings to compensate for minor misalignments (max 0.5° angular tolerance). Lubricate through air inlet port during initial setup.
| Property | Property Value |
|---|---|
| sku | PBD6X15S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | <15mm> |
