Airtac PBD Pen-shaped Double Rod Cylinder PBD6X20
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X20 Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X20
- Type: Double-acting pen-type cylinder
- Bore size: 6mm
- Stroke: 20mm (±10mm adjustable)
- Operating pressure: 0.15–0.8 MPa
- Port size: M3x0.5 (dual ports both ends)
- Piston rod material: SUS304 stainless steel
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Cushion type: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Weight: 42g ±2g
- Dimensions: 62mm(L) × 19mm(W) × 19mm(H)
- Mounting options: Front flange (MF1), side lugs (M9)
- Rod end thread: M3 male thread (both ends)
Ultra-compact dual-rod cylinder with symmetrical force output, featuring through-rod design for precise bidirectional positioning. The nickel-plated piston rod and self-lubricating bushings ensure smooth operation in cleanroom environments. Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (optional oil-free operation).
- Semiconductor wafer handling robots
- Optical lens positioning systems
- Medical pipette actuation mechanisms
- 3D printer nozzle adjustment
- Precision clamping in watchmaking
Installation note:
Maximum allowable lateral load 1.5N. Use alignment jigs during mounting to ensure rod parallelism within 0.05mm. Lubricate every 500,000 cycles under normal conditions (every 100,000 cycles in dry environments).
| Property | Property Value |
|---|---|
| sku | PBD6X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | <20mm> |
