Airtac PBD Pen-shaped Double Rod Cylinder PBD6X20S
$20.69
Regular price
$28.19
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PBD6X20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
PBD Series Double-Rod Cylinders (AirTAC)
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
Installation tips:
Mount using provided M3 threaded holes on base. Maintain parallel alignment within 0.05mm/meter.
Use clean dry air with 5-40μm filtration. For vertical mounting, install rod-end down to prevent debris accumulation.
Note:
Maximum side load capacity 1.5N. Avoid angular misalignment exceeding ±2°.
When using in cleanroom environments, specify optional nickel-plated version (PBD6X20S-Ni).
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X20S Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X20S
- Type: Double-rod compact cylinder (non-rotating)
- Bore size: 6mm (0.24")
- Stroke: 20mm (0.79")
- Operating pressure: 0.05–0.9 MPa
- Port thread: M5×0.8 (standard) or NPT1/8 optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber (standard), optional PU seals
- Temperature range: -10℃ to 80℃ (NBR seals)
- Cushioning: Fixed cushion (both ends)
- Weight: 0.12 kg (0.26 lbs)
- Dimensions: 50mm(L) × 16mm(W) × 16mm(H)
- Rod diameter: 3mm (dual rods)
- Max theoretical force: 25.4N @0.9MPa
- Lubrication: Pre-lubricated (DOP equivalent)
Ultra-compact dual-rod cylinder with symmetrical force output, designed for precision linear motion in confined spaces. Features anti-rotation design with guide slots and hardened rods for side load resistance. Ideal for applications requiring synchronized bidirectional movement with minimal installation footprint.
Typical Applications:
- Semiconductor wafer handling robots
- Micro-dispensing systems in PCB assembly
- Optical lens positioning mechanisms
- Laboratory automation grippers
- Medical device actuation systems
- Precision clamping fixtures
Installation tips:
Mount using provided M3 threaded holes on base. Maintain parallel alignment within 0.05mm/meter.
Use clean dry air with 5-40μm filtration. For vertical mounting, install rod-end down to prevent debris accumulation.
Note:
Maximum side load capacity 1.5N. Avoid angular misalignment exceeding ±2°.
When using in cleanroom environments, specify optional nickel-plated version (PBD6X20S-Ni).
| Property | Property Value |
|---|---|
| sku | PBD6X20S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | <20mm> |
