Airtac PBD Pen-shaped Double Rod Cylinder PBD6X25S
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PBD6X25S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
PBD Series Double-Rod Cylinders (AirTAC)
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
Installation guidelines:
Maintain 0.5mm minimum clearance between rods and adjacent components.
For vertical mounting, use air pressure ≤0.5MPa. Lubricate through air supply
(oil mist 1-2 drops/m³). Avoid lateral loads exceeding 2N.
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X25S Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X25S
- Type: Compact double-rod cylinder (pen-style design)
- Bore size: 6mm
- Stroke: 25mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Built-in elastic buffer (both ends)
- Mounting style: Front flange/back flange/foot mounting (M3 thread)
- Port size: M5x0.8 (standard) or Rc1/8 optional
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR (nitrile rubber)
- Weight: 0.12kg (excluding accessories)
- Dimensions:
- Overall length: 60mm (at mid-stroke position)
- Body diameter: Φ16mm
- Rod diameter: Φ3mm (double rods)
- Rod length: 25mm (extended from each end)
- Mounting base: 16mm x 16mm square profile
- ISO standard: Compliant with ISO 6432 (miniature cylinders)
Ultra-compact dual-action pneumatic cylinder featuring symmetrical force output and space-saving design. The chrome-plated piston rods provide enhanced corrosion resistance, while the anodized barrel ensures durability in humid environments. Requires filtered air (5-40μm) with recommended lubrication ISO VG32.
Typical Applications:
- Precision clamping in SMT equipment
- Micro-positioning in semiconductor handling robots
- Valve actuation in medical analyzers
- Paper feed mechanisms in compact printers
- Orientation adjustment in optical lens assemblies
Installation guidelines:
Maintain 0.5mm minimum clearance between rods and adjacent components.
For vertical mounting, use air pressure ≤0.5MPa. Lubricate through air supply
(oil mist 1-2 drops/m³). Avoid lateral loads exceeding 2N.
Cycle Life: 5,000km travel distance (NBR seals) or 8,000km (optional FKM seals)
Max Speed: 500mm/s (cushioned operation), 1500mm/s (non-cushioned)
Max Speed: 500mm/s (cushioned operation), 1500mm/s (non-cushioned)
| Property | Property Value |
|---|---|
| sku | PBD6X25S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | <25 mm> |
