Airtac PBD Pen-shaped Double Rod Cylinder PBD6X30
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X30 Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X30
- Type: Double-acting pen-type cylinder with dual rod outputs
- Bore size: 6mm (precision honed tube)
- Stroke: 30mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable cushioning (both ends)
- Mounting: Radial mounting holes + front flange (M4 thread)
- Material: Aluminum alloy barrel, stainless steel rods (SUS304)
- Seals: NBR rubber (standard), optional FKM for high temp
- Temperature range: -20℃ to 80℃
- Weight: 0.12kg (without accessories)
- Dimensions: 75mm(L) × 20mm(Ø) × 18mm(W) (mounting width)
- Rod diameter: 3mm (dual rods, symmetrical output)
- Max speed: 500mm/s (with cushioning engaged)
- Lubrication: Pre-lubricated (Grease-free operation available)
Ultra-compact dual-rod cylinder designed for bi-directional force applications requiring precise linear motion. Features integrated mounting flexibility with 360° rotatable rod ends and corrosion-resistant construction. The symmetrical rod design eliminates lateral load imbalance, making it ideal for alignment-critical setups. Requires 5μm filtered air.
- Precision clamping in PCB assembly robots
- Valve actuation in medical analyzers
- Lens positioning systems in optical equipment
- Cartesian coordinate gripper mechanisms
- Automated reagent dispensing systems
Installation note:
Maintain parallel alignment within 0.05mm/m during mounting. Use rod-end bearings for
angular motion conversion. For vertical installations, specify "UP" orientation mark
facing upward to optimize lubrication distribution.
| Property | Property Value |
|---|---|
| sku | PBD6X30 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | 30mm |
