Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X35 Pen-Type Double Rod Cylinder Specifications
- Model: PBD6X35
- Type: Double-acting, dual rod compact cylinder
- Bore size: 6mm
- Stroke: 35mm
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Front flange with 2x M3 threaded holes
- Port size: M5x0.8 (Rc1/8 adapter optional)
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Weight: 0.15kg ±5%
- Dimensions: 100mm(L) × 20mm(W) × 25mm(H)
- Protection rating: IP54 (standard wiper seal)
- Piston speed: 50–700mm/s (optimal range)
Ultra-slim dual-rod cylinder featuring synchronized bidirectional movement and precise linear motion control. The through-rod design eliminates rotational torque, making it ideal for precision alignment tasks. Includes anti-rotation guide slots (2mm depth) and dual magnet grooves for sensor mounting. Requires 5μm filtered air with ISO VG32 lubricant.
- PCB board clamping mechanisms
- Micro-dispenser valve actuation
- Optical lens positioning systems
- Semiconductor wafer handling robots
- Laboratory syringe pump drives
Installation note:
Align mounting surface flatness within 0.1mm. Use flexible couplings when connecting to rigid mechanisms. Lubricate through air port with 1-2 drops of pneumatic oil monthly in dry environments.
| Property | Property Value |
|---|---|
| sku | PBD6X35 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | 35mm |
